| 型號 | 阻值(?) | 尺寸(inch) | 額定功率 | 溫度系數值(ppm/℃) | 阻值精度 | 說明書/特性 |
|---|---|---|---|---|---|---|
| RS-10L106JT | 10MΩ | 2010 | 3/4W | ±250 | ±5% | |
| RS-1210L106JT | 10MΩ | 1210 | 1/2W | ±250 | ±5% | |
| RS-06K106JT | 10MΩ | 1206 | 1/4W | ±100 | ±5% | |
| RS-06L106JT | 10MΩ | 1206 | 1/4W | ±250 | ±5% | |
| RS-05K106JT | 10MΩ | 0805 | 1/8W | ±100 | ±5% | |
| RS-05L106JT | 10MΩ | 0805 | 1/8W | ±250 | ±5% | |
| RS-03L106JT | 10MΩ | 0603 | 1/10W | ±250 | ±5% | |
| RS-03K106JT | 10MΩ | 0603 | 1/10W | ±100 | ±5% | |
| RC-02U106JT | 10MΩ | 0402 | 1/16W | ±400 | ±5% | |
| RC-01U106JT | 10MΩ | 0201 | 1/20W | ±400 | ±5% | |
| RC-005L106JT | 10MΩ | 01005 | 1/32W | ±250 | ±5% | |
| RS-10L1005FT | 10MΩ | 2010 | 3/4W | ±250 | ±1% | |
| RS-1210L1005FT | 10MΩ | 1210 | 1/2W | ±250 | ±1% | |
| RS-06K1005FT | 10MΩ | 1206 | 1/4W | ±100 | ±1% | |
| RS-06L1005FT | 10MΩ | 1206 | 1/4W | ±250 | ±1% |
